Extrusion mesh – multi-purpose

Extrusion mesh, multi-purpose

Extruded mesh is a stable and versatile mesh suitable for many applications. Its two-layer structure offers the advantage of superior dewatering. Its dimensional stability makes it well suited for reinforcement and support purposes.

Top Zeven offers a wide range of extruded meshes in PP, HDPE, LDPE, PA, PBT and EVA. All plastics have their own characteristics, properties and resistances, as can be found in the downloads section. Most types we keep in stock and are available for fast delivery.

Looking for a specific solution?

Tell us, we are happy to think with you. Contact us or call us directly at +31(0)23 5319051.

Polypropylene (PP)

Polypropylene 5066 — Polypropylene 5066. Width: 0.7 (m) Length: 200 – 400 (lm). Weight: 70 (g / m2). Color: natural. Mesh size: 3 x 3 (mm).

Polypropylene 5205 — Polypropylene 5205. Width: 0.5 (m) Length: 25 (lm). Weight: 500 (g / m2). Color: natural. Mesh size: 2.8 x 2.8 (mm). Thickness: 1.7 (mm)

Polypropylene 5230 — Polypropylene 5230. Width: 1 (m) Length: 25 (lm). Weight: 420 (g / m2). Color: natural. Mesh size: 1.4 x 1.6 (mm). Thickness: 1.3

Polypropylene 5323 — Polypropylene 5323. Width: 0.67 (m) Length: 200 (lm). Weight: 130 (g / m2). Color: white / blue. Mesh size: 1 x 1.8 (mm).

Polypropylene 8502 — Polypropylene 8502. Width: 1.06 (m) Length: 50 (lm). Weight: 528 (g / m2). Color: natural. Mesh size: 4.5 x 3.6 (mm). Thickness: 1.4

PP6281 (PP28M) Width: 1016mm, mesh 2 x 2mm. Length: 300 m., Thickness: 0.7 mm

PP6246 (PP48M) Width: 1016mm, mesh 3 x 3mm. Length: 180 m., Thickness: 1.2 mm

PP6247 (PP65M) Width: 1016mm, mesh 3.5 x 3.5mm. Length: 125 m., Thickness: 1.62 mm

PP6248P, width 1016, length 100m., Thickness 2mm.

PP 6248 (PP80M) width: 1016mm, mesh 4 x 4mm. Length: 100 m., Thickness: 2 mm

High density polyethylene (HDPE)

Polyethylene 5000 — Polyethylene 5000. Material: HDPE. Width: 1.64 (m) Length: 25 (lm). Weight: 1000 (g / m2). Color: black. Mesh size: 5.6 x 6 (mm). Thickness: 4.3 (mm)

Polyethylene 5001 — Polyethylene 5001. Material: HDPE. Width: 1.64 (m) Length: 25 (lm). Weight: 740 (g / m2). Color: black. Mesh size: 8.4 x 11 (mm). Thickness: 3.6 (mm)

Polyethylene 5002 — Polyethylene 5002. Material: HDPE. Width: 1.64 (m) Length: 25 (lm). Weight: 650 (g / m2). Color: black. Mesh size: 12 x 15 (mm). Thickness: 3.5 (mm)

Polyethylene 5003 — Polyethylene 5003. Material: HDPE. Width: 1.64 (m) Length: 25 (lm). Weight: 590 (g / m2). Color: black. Mesh size: 17 x 19 (mm). Thickness: 4 (mm)

Polyethylene 5004 — Polyethylene 5004. Material: HDPE. Width: 1.64 (m) Length: 25 (lm). Weight: 670 (g / m2). Color: black. Mesh size: 21 x 24 (mm). Thickness: 5.2 (mm)

Polyethylene 5005 — Polyethylene 5005. Material: HDPE. Width: 1.64 (m) Length: 25 (lm). Weight: 540 (g / m2). Color: black. Mesh size: 30 x 29 (mm). Thickness: 4.3 (mm)

Polyethylene 8446 — Polyethylene 8446. Material: HDPE. Width: 0.6 (m) Length: 50 (lm). Weight: 216 (g / m2). Color: white. Mesh size: 5 x 5 (mm). Thickness: 1.1 (mm)

Polyethylene 5016 — Polyethylene 5016. Material: HDPE. Width: 0.5 (m) Length: 25 (lm). Weight: 420 (g / m2). Color: white. Mesh size: 2 x 1.8 (mm). Thickness: 1.6 (mm)

Polyethylene 5216 — Polyethylene 5216. Material: HDPE. Width: 1 (m) Length: 20 (lm). Weight: 420 (g / m2). Color: natural. Mesh size: 4.5 x 4.5 (mm). Thickness: 1.9

Polyethylene 5018 — Polyethylene 5018. Material: HDPE. Width: 0.5 (m) Length: 25 (lm). Weight: 240 (g / m2). Color: white. Mesh size: 3.4 x 3.2 (mm). Thickness: 1.3 (mm)

Polyethylene 5208 — Polyethylene 5208. Material: HDPE. Width: 1 (m) Length: 20 (lm). Weight: 420 (g / m2). Color: natural. Mesh size: 10×10 (mm). Thickness: 2.4

Polyethylene 5213 — Polyethylene 5213. Material: HDPE. Width: 1 (m) Length: 25 (lm). Weight: 420 (g / m2). Color: natural. Mesh size: 18 x 18 (mm). Thickness: 3.5

Meshes available on request

Polypropylene 5361 — Polypropylene 5361. Width: 1.2 (m) Length: 50 (lm). Weight: 192.5 (g / m2). Color: green / white / brown. Mesh size: 2 x 2 (mm).

Polypropylene 5340 — Polypropylene 5340. Width: 1.04 (m) Length: 100 (lm). Weight: 103 (g / m2). Color: yellow. Mesh size: 2 x 2 (mm).

Polypropylene 5307 — Polypropylene 5307. Width: 0.63 (m) Length: 200 (lm). Weight: 77 (g / m2). Color: white / blue. Mesh size: 1.5 x 1.5 (mm).

Polypropylene 5286g — Polypropylene 5286g. Width: 2 (m) Length: 200 (lm). Weight: 195 (g / m2). Color: natural. Mesh size: 2 x 2 (mm).

Polypropylene 5286 — Polypropylene 5286. Width: 2 (m) Length: 215 (lm). Weight: 161 (g / m2). Color: natural. Mesh size: 2 x 2 (mm).

Polypropylene 5231 — Polypropylene 5231. Width: 0.05 (m) Length: 50 (lm). Weight: 25 (g / m2). Color: green. Mesh size: 12 x 13 (mm).

Polypropylene 5218 — Polypropylene 5218. Width: 0.6 (m) Length: 200 (lm). Weight: 75 (g / m2). Color: natural. Mesh size: 9 x 6 (mm).

Polypropylene 3116c — Polypropylene 3116c. Width: 1.66 (m) Length: 500 (lm). Weight: 95 (g / m2). Color: natural. Mesh size: 6 x 5.5 (mm).

PP 6032. flow capacity: 247gr / min-m, Material: PP, Weight: 170gr / m2, Thickness: 1.10mm, Widht: 920mm, Length: 200m

Polypropylene 8321 — Polypropylene 8321. Width: 0.7 (m) Length: 100 (lm). Weight: 201 (g / m2). Color: black. Mesh size: 18 x 22 (mm). Thickness: 1.7

UG9seXByb3B5bGVlbiA1MTcz — UG9seXByb3B5bGVlbiA1MTczLiBXaWR0aDogMSwxOCAobSkKTGVuZ3RoOiA2MjAgKGxtKS4gV2VpZ2h0OiAxNDggKGcvbTIpLiBDb2xvdXI6IG5hdHVyYWwuIE1lc2ggc2l6ZTogMiB4IDIgKG1tKS4=

Polypropylene 6275 flame retardant — Polypropylene 6275 flame retardant. Width: 0.97 (m) Length: 310 (lm). Weight: 145 (g / m2). Color: white. Mesh size: 3.5 x 3.5 (mm).

Polypropylene 6353 — Polypropylene 6353. Width: 1.2 (m) Length: 200 (lm). Weight: 100 (g / m2). Color: natural. Mesh size: 2 x 2.5 (mm). Thickness: 0.6

Polyethylene Low Density 5015 — Polyethylene Low Density 5015. Material: LDPE. Width: 0.5 (m) Length: 25 (lm). Weight: 880 (g / m2). Color: white. Mesh size: 3 x 3.2 (mm). Thickness: 3.2

Polyethylene 5102 — Polyethylene 5102. Material: HDPE. Width: 0.295 (m) Length: 300 (lm). Weight: 180 (g / m2). Color: black. Mesh size: 3 x 3 (mm).

Polyethylene 5052 — Polyethylene 5052. Width: 1.20 (m) Length: 50 (m). Weight: 257 g / m2. Color: green / white / gray. Mesh size: 1x (mm) Type: PEHD

Polyethylene 5017 — Polyethylene 5017. Material: LDPE. Width: 0.5 (m) Length: 25 (m). Weight: 480 g / m2. Color: white. Mesh size: 1.8 x 1.8 (mm). Thickness: 1.6.

Polyethylene 8288 — Polyethylene 8288. Material: HDPE. Width: 1 (m) Length: 50 (lm). Weight: 360 (g / m2). Color: white. Mesh size: 10×10 (mm). Thickness: 1.7 (mm)

PBT 6288. flow capacity: 38gr / min-m, Material: PBT (high temp.), Weight: 150gr / m2, Thickness: 0.60mm, Width: 1200mm, Length: 200m

PBT 6282, roll 200 x 1.2 m, weight 100 g/m², mesh 2.5 x 1.5 mm, thickness 0.5 mm.

PA 6281, PA6, roll 30 x 1.2 m, weight 450 g/m², mesh 9 x 8 mm, thickness 2.8 mm.

PA 6089. flow capacity: 52gr / min-m, Material: PA6 (high temp.), Weight: 145gr / m2, Thickness: 0.65mm, Width: 1200mm, Length: 200m

EVA 5975, roll 30 x 1.2 m, weight 550 g/m², mesh 2.5 x 2.5 mm, thickness 1.6 mm.

EVA 5944, roll 30 x 0.78 m, weight 980 g/m², mesh 6 x 5.5 mm, thickness 4 mm.
